5500m³/H Fully Hydraulic Cutter Suction Submersible Dredge

Leader Dredger Co., Ltd
Contact Now

5500m³/H Fully Hydraulic Cutter Suction Submersible Dredge

Brand Name : Leader Dredger

Model Number : LD5500SP

Certification : ISO 9001

Place of Origin : China

MOQ : One Ship

Price : Free Consultation

Payment Terms : L/C, T/T

Supply Ability : 20

Delivery Time : Peak season lead time: 1-3 months ; Off season lead time: 1-3 months

Packaging Details : In Container Or Bulk Vessel

Type : Submersible Pump Cutter Suction Dredger

Power Type : Diesel

Inch : 22 Inch

Dredging depth (m) : MAX 22M

Main engine power (kw) : 1425

Auxiliary engine power (kw) : 447

Pipe diameter (mm) : 600

Application : Coral Dredging, Port Dredging

Customized : Customized

Condition : New

Contact Now



5500m³H Fully Hydraulic Cutter Suction Dredger Developed And Built By Leader Dredger



1. About Leader Dredger Submersible Cutter Suction Dredger Service



1,Leader Dredger has signed a long-term after-sales service agreement with customers.


2,We can provide reasonable and practical designs according to customer requirements.


3,We send engineers to assemble and test the machine within the period stipulated in the contract.


4,During the warranty period, if quality problems occur, we will provide free repairs.


5,We provide our customers with free operation and maintenance training.


6,We offer high quality accessories at low prices.


7,We will keep records for customers who have been following up for a long time.



2. Submersible Pump Cutter Suction Dredger Feature


1. Easy to assemble and dismantle

2. One man operation

3. Advanced hydraulic system

4. Spare parts available

5. Customizations on users'demand

6. Completely tested before deliverie

7. Advanced profssional design

8. with air conditioning

9. Water cooled diesel engines

10. Deliver by road, rail or sea


5500m³/H Fully Hydraulic Cutter Suction Submersible Dredge



3. Leader Dredger LD5500SP Technical Specifications

A . Dredging Features

Standard dredging depth(m) Maximum mixture Max 20m
capacity(m/h) 5500m³/h
Solid capacity(approx) 1600m³/h
Dredging pump mode 600/550mm



B . Principal characteristics



Overall length(m) 43m
Breadth(m) 10m
Draught(m) 1.5m
Discharge distance(m) 2000m
Total dry weight approx(MT) 300MT
Ladder length 31m



C . Dredge pump: Australia technology Pump



By alloy cast iron material for better abrasion resistance, abrasive, hardness, more than68HRC. Bigger working capacity, more efficiency, driven through gearbox.
Maximum mixture capacity(m/h) 5500m³/h
Solid capacity(approx) 1600m³/h







5500m³/H Fully Hydraulic Cutter Suction Submersible Dredge



4. Our Parts



- CUMMINS engine (primary and auxiliary)-USA



- WARMAN Pump Technology - Australia



- REXROTH Hydraulic System - Germany



- SCHNEIDER ELECTRIC SYSTEM-Germany



The above parts have a 1-year manufacturer warranty and lifetime support.



5. FAQ



1. Are our products certified or patented?



-Yes, we only provide certified products.



2. Can we provide good after-sales service?





-Yes, the warranty period of all our products is one year, and all spare parts will always provide fast and cheap service.



3. What are the main products of our company?



-Our main product is cutter suction dredger.



4. Is our company a direct or indirect manufacturer?



-Our company is a direct manufacturer.



6. How To Choose Cutter Suction Dredger



5500m³/H Fully Hydraulic Cutter Suction Submersible Dredge



7. Leader Dredger Customer



5500m³/H Fully Hydraulic Cutter Suction Submersible Dredge



8. Submersible Pump Cutter Suction Dredger Testing Picture





5500m³/H Fully Hydraulic Cutter Suction Submersible Dredge
